WNFB-265AXI(BT)

802.11ax/ac/a/b/g/n Industrial Grade, WiFi Combo, M.2 2230 Module(WiFi 6), 2T2R



  • Chipset: Broadcom
  • Antenna: 2 x IPEX MHF4 connectors, 2T2R
  • Interface: PCIe: WLAN
  • Output Power up to 18.5dBm
  • Support: Linux, Android



Share:
Enquire Here DatasheetDownload Driver

Product Overview



WNFB-265AXI(BT) is a 802.11ax WiFi 6 Combo M.2 2230 (KEY E) Module, 802.11ax allow efficient allocation of low data-rate connections, improve the battery life of IoT sensors, and extend the range of Wi-Fi signals. WNFB-265AXI(BT) M.2 module brings steady, high-speed Wi-Fi connectivity for Remote control, Smart manufacturing, shop, home, TV etc. The new 802.11ax standard with its unique features such as OFDMA, 1024QAM, Target Wake Time (TWT). 802.11ax (WiFi 6) enables smooth streaming of high-resolution videos, fewer dropped connections and faster connections farther away from the router and in dense environments.



WNFB-265AXI(BT) M.2 2230 (KEY E) module can support Multi-User MIMO (MU-MIMO) technology to increase channel capacity when simultaneously servicing multiple devices using the same frequency chunks and can accomplish up to speed of 1200Mbps with dual stream.

Suitable Application



  • Industrial PC
  • In Vehicle PC
  • In Vehicle Router
  • Outdoor IPTV
  • Vehicle mounted front
  • Rear Terminal UAV
  • Robot
  • Intelligent Gateway

Certifications



FCC Certification Logo CE Certification Logo MIC Certification Logo IC Certification Logo
USA EU Region Japan Canada

Environmental Compliance



ROHS Reach

Specification



STANDARD
WI-FI IEEE 802.11ax/ac/a/b/g/n
Chipset Broadcom
Host Interface WLAN : PCIe
RADIO
Antenna 2 x IPEX MHF4 connectors
Operating Frequency 802.11ax/ac/a/b/g/n ISM Band
2.400GHz~2.4835GHz

5.150GHz~5.850GHz

*Subject to local regulations

MODULATIONS
802.11b DSSS (DBPSK, DQPSK, CCK)
802.11g OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11n OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11a OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11ac OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM)
802.11ax OFDMA (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM)
POWER & SENSITIVITY
WiFi Power – TX (± 2dBm) Sensitivity – RX
11b @ 11Mbps 18.5dBm ≤ -88dBm
11g @ 54Mbps 12dBm ≤ -77dBm
11gn HT20 @ MCS 7 12dBm ≤ -75dBm
11a @ 54Mbps 14.5dBm ≤ -76dBm
11an HT20 @ MCS 7 13.5dBm ≤ -73dBm
11an HT40 @ MCS 7 11dBm ≤ -70dBm
11ac VHT80 @ MCS 9 9dBm ≤ -57dBm
11ax HE20 @ HE 7 13.5dBm ≤ -69dBm
11ax HE40 @ HE 7 11dBm ≤ -68dBm
11ax HE80 @ HE 9 9dBm ≤ -60dBm
POWER CONSUMPTION
Continue TX 660mA
Continue RX 201mA
ENVIRONMENTAL
Operating Voltage DC 3.3V
Temperature Range -40 ~ 85°C (Operating) -40 ~ 105°C (Storing)
Humidity (Non-Condensing) 10 ~ 95% (Operating) 5 ~ 95% (Storing)
SIZE
Dimension (MM) 30mm(±0.15mm) x 22mm(±0.15mm) x 2.8mm(±0.2mm)
Weight ≦3.5g
SOFTWARE
Driver Linux
Android
Security 64/128-bits WEP, WPA, WPA2, WPA3, 802.1x
Miscellaneous
Warranty Period 12 Month
HS Code 8517620050
