AP6398S

802.11ac/a/b/g/n WiFi Combo Sip Module (WiFi 5), 2T2R



  • Chipset: Broadcom
  • Antenna: External
  • Interface: WLAN: SDIO 3.0/2.0
  • Support: Linux, Android



Share:
Enquire Here DatasheetDownload Driver

Product Overview



AP6398S is a fully Wi-Fi combo functionalities module (WiFi 5) with seamless roaming capabilities and advance security, also it could interact with different vendors’ 802.11a/b/g/n/ac 2×2 Access Points with MIMO standard and can accomplish up to speed of 867Mbps with dual stream in 802.11n to connect the wireless LAN. Furthermore AP6398S included SDIO interface for Wi-Fi, UART/ PCM interface for BT.



In addition, this compact module is a total solution for a combination of Wi-Fi combo technologies. The module is specifically developed for tablet, OTT box and portable devices.

Suitable Application



This compact module is a total solution for a combination of 11ac WiFi 5 technologies. The module is specifically developed for tablets, Tower Speaker, OTT box, and portable devices.

Certifications



Environmental Compliance



ROHS Reach

Specification



STANDARD
WI-FI IEEE 802.11 ac/a/b/g/n 2T2R Wi-Fi Combo Module
Chipset Broadcom
Host Interface WiFi: SDIO 3.0/2.0

RADIO
Antenna External
Operating Frequency 2.4GHz ISM Band

2.400GHz~2.4835GHz

5GHz UNII Band

5.150GHz~5.850GHz

*Subject to local regulations*

MODULATIONS
802.11b DSSS (DBPSK, DQPSK, CCK)
802.11g/n OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11a OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11n OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11ac OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM)
ENVIRONMENTAL
Temperature Range -30~ 75°C (Operating) -40 ~ 85°C (Storing)
Humidity (Non-Condensing) 10 ~ 95% (Operating)
SIZE
Dimension (MM) 15mm(±0.2mm) x 13mm(±0.2mm) x 1.85mm(Max.)
Weight 0.6g
SOFTWARE
Driver Linux, Android
Security
Miscellaneous
Warranty Period 12 Month
HS Code 8517620050
