Sample Status: Available for Ordering
Ant. AD-311N is a dual-band dipole antennahe 2.4 to 2.5 GHz and 5.15 to 5.895 GHz band with 2.67dBi and 4.88dBi gain on each band. This antenna has a I-PEX /MHF4 connector can provides broad coverage and ideally suited for wireless LAN.
 |
 |
||||
| ROHS | Reach |
DESCRIPTION |
||
| Model Name | Ant. AD-311N | |
| Color | Black | |
ELECTRICAL CHARACTERISTICS
|
||
| Antenna Type Material | Dual-Band Dipole | |
| Operating Frequency Range | 2400 to 2500 MHz
5150 to 5895 MHz |
|
| Polarization Type | Liner ; Vertical | |
| Type of Radiation | Toroidal | |
| Peak Gain | 2.4-2.5GHz@2.67dBi 5.15-5.895GHz@4.88dBi |
|
| Impedance | 50 Ohms | |
| V.S.W.R. | 2.0 : 1 Max. | |
| Connector Type | MHF4 | |
| Antenna Material | FR4 | |
| Cable | Ø1.13 L:250mm | |
